Bostitch SC77XEB-E C-RINGER-15 19 OP/8 78MM NOSE | Collated Fasteners

Bostitch SC77XEB-E Pneumatic C Ringer — 78mm Extended Nose

The Bostitch SC77XEB-E is a pneumatic C ringer from the Ring15 series with a 78mm extended nose, giving improved reach for deep or confined ring closing applications. With a 130-ring capacity and trigger operation, it’s suited to upholstery, packaging, and agricultural use.

Key Features

• 78mm extended nose for improved reach in confined spaces
• Trigger operated for fast, controlled ring closing
• Air return mechanism for consistent performance
• Rubber comfort grip for reduced operator fatigue
• 130 ring magazine capacity

Specifications

• Power: Pneumatic
• Ring series: Ring15
• Wire diameter: 1.8mm
• Crown: 20.3mm
• Opened size: 15mm
• Magazine capacity: 130 rings
• Operating pressure: 4.2–7.0 bar (60–100 PSI)
• Air consumption: 0.7 L/shot @ 5.6 bar
• Weight: 1.7 kg
• Dimensions: 225mm (L) x 378mm (W) x 86mm (H)

Compatible Fasteners (Ring15 Series)

• RING15G100B/P — galvanised, 10,000/box
• RING15SS100B — stainless steel, 10,000/box

Applications

• Upholstery and furniture manufacture
• Packaging and agricultural use
• Deep or confined ring closing applications
