Bostitch RAB-19-E AR Roll Format Pneumatic Carton Sealer

The Bostitch RAB-19-E is a pneumatic roll format carton sealer from the RAB series, designed for busy production and despatch environments. With a 1,000-staple roll capacity and comfortable hand pad, it minimises reloading downtime and delivers a consistent clinch on single and double wall cartons.

Key Features

• Aluminium housing with rubber comfort grip and hand pad
• Trigger operated with rear exhaust
• Roll format for minimal reloading on high-volume lines
• Mounting lugs for line integration
• Hanging port for storage

Specifications

• Power: Pneumatic
• Staple range: 15–19mm (AR series)
• Wire diameter: 0.9–2.3mm
• Magazine capacity: 1,000 staples
• Operating pressure: 4.90–7.10 bar (71–103 PSI)
• Air consumption: 1.13 L/shot @ 5.6 bar
• Air fitting: 1/4 BSP
• Weight: 2.40 kg
• Dimensions: 234 x 115 x 233 mm

Compatible Fasteners (AR Series)

• 1451500Z — 35mm crown, 15mm, liquor finish, 24,000/box
• 1451800Z — 35mm crown, 19mm, liquor finish, 24,000/box

Applications

• High-volume carton top sealing
• Production and despatch lines
• Single and double wall carton sealing
