MAX RB401-T Stand Up Re-Bar Tying Tool

MAX RB401-T Stand Up Re-Bar Tying Tool

£5,130.00 GBP
£5,130.00 GBP
Sale Sold out
Shipping calculated at checkout.

Rebar RB401T-E Tying Tool up to 20mm x 20mm with 1.0 mm wire

Stand Up Rebar Tying Tool up to 20mm X 20mm

Applications

  • Road and Bridge
  • Foundations
  • Water retaining Structures
  • Commercial Buildings
  • Water Treatment Tanks

FEATURES

  • DOUBLE THE SPEED
    The Dual Wire Feeding Mechanism increases productivity.
  • COST SAVINGS
    The Wire Pull Back Mechanism dispenses the precise amount of wire needed to form a tie reducing wire usage.
  • THE TWINTIER
    The TwinTier can tie 4000 ties per battery charge and up to 240 ties per coil of wire (on 13mm x 13mm rebar).
  • SHORTER TIE HEIGHT
    The TwinTier's Wire Bending Mechanism (Pat. Pending) produces a shorter tie height. Less concrete is needed to fully cover a wire tie.
  • A LARGE JAW
    A large jaw enables the TwinTier to tie up to a 20mm x 20mm rebar.
  • AN EASY PUSH GEAR
    An easy push gear release effortlessly opens gears to quickly feed wire when loading the tool.

SPECIFICATIONS

DIMENSIONS

1100mm(H) x 408mm(W) x 322mm(L)
MINIMUM TIES PER COIL
155
MAXIMUM TIES PER COIL
260
APPLICABLE WIRE PRODUCT
TW1061T / 19Ga, TW1061T-PC / 19Ga, TW1061T-EG / 19Ga, TW1061T-S / 19Ga,
APPLICABLE REBAR SIZE
10 x 10 - 20 x 20, up to 13 x 13 x 13 x 13(Unit: mm)
TIES PER CHARGE
4000
TIE SPEED
0.7 sec
TIE WRAPS
2
BATTERY CHARGE TIME
65 minutes full charge (50 minutes 80%)

CONSUMABLES / ACCESSORIES

Tool, Owners manual, Battery, Charger, Carry case
