Bostitch P51-5B-E Pneumatic Stapling Plier

The Bostitch P51-5B-E is a compact, lightweight pneumatic stapling plier from the versatile P51 series. Its deep 150mm jaw depth makes it ideal for a wide range of applications — from carton lids and trays through to sealing end caps for postal and storage tubes. Compatible with an optional C-blade attachment for added versatility.

Key Features

• Deep 150mm jaw depth for wide application range
• Compact and lightweight design
• Mounting lug for line integration
• Compatible with optional C-blade attachment
• 168 staple magazine capacity

Specifications

• Power: Pneumatic
• Staple series: SB5019
• Crown: 12.7mm
• Staple length: 10–15mm
• Jaw depth: 150mm
• Magazine capacity: 168 staples
• Operating pressure: 2.10–3.90 bar (30–55 PSI)
• Air consumption: 0.4 L/shot @ 5.6 bar
• Air fitting: 1/4 BSP
• Weight: 2.04 kg
• Dimensions: 370mm (L) x 55mm (W) x 270mm (H)

Compatible Fasteners (SB5019 Series)

• SB501910Z — 12.7mm crown, 10mm, galvanised, 8,000/box
• SB501915Z — 12.7mm crown, 15mm, galvanised, 4,000/box

Applications

• Carton lids and trays
• Postal and storage tube end caps
• Packaging and despatch operations
